SA358 type 316 tubing spools manufacturer in India
Supplier of A358 Gr 316 spool flange with A403 but weld fittings and A182 F316 flanges
ASTM A358 Grade 316 pipe spools specification
Sizes
- 0.5" to 24"
A358 Gr 316 flanged spool piece heat treatment
- PWHT up to 1200°C furnaces
Wall thickness
- 0.5mm to 6.35mm
ASTM A358 316 tubing spool welding methods
- 1G TIG
- 1G MIG
- MIG/ MAG
- FCAW
- GTAW
- SAW
- GMAW
- SMAW
A358 type 316 fabricated spools standard
- ASME B16.9
- ANSI B16.9
- ASME B16.28
- ANSI B16.28
- ANSI B16.25
A358 tp316 custom pipe spool fabrication process
- Cutting
- Bevelling
- Fitting
- Welding
- Quality control
- Stress-relieving
- Hydro testing
- Surface finishing
ASTM A358 grade 316 class 2 spool piece flange finishes
- Mill finish
- Polished finish
- Brushed finish
Fabrication parts
- Tee / Reducing tee
- Cross / Reducing cross
- 45° / 90°elbow (LR, SR)
- Weldneck / Blind / Slip on flanges
ASTM A358 gr 316 cl1 fabricated pipe spools welding standard
- Bending PFI ES24
- Welders as per API1104
- Fabrication Tolarance – PFI ES3
- ASME section IX
ASTM A358 grade 316 class 2 fabricated pipe spools increases your assembly speed and productivity
Specialized ASTM A358 316 EFW Pipes Spools Manufacturer in India
A358 316 fabrication spool Length
| Size NB | Inches | 1/2" | 3/4" | 1" | 1.1/2" | 2" | 3" | 4" | 6" | 8" | 10" | 12" |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | 15 | 20 | 25 | 40 | 50 | 80 | 100 | 150 | 200 | 250 | 300 | |
| Length Min. | mm | 90 | 90 | 90 | 95 | 110 | 120 | 125 | 140 | 150 | 165 | 170 |
| Length Max. | mm | 6000 | 6000 | 6000 | 6000 | 6000 | 6000 | 6000 | 6000 | 3000 | 3000 | 3000 |
| PTFE liner Thickness | mm | 2.8 | 3.3 | 3.3 | 3.3 | 3.3 | 3.3 | 4.5 | 5.5 | 8 or 4.5 | 9 or 5 | 9 or 5 |
A358 Gr 316 spool vs CS pipe spool
| Aspect | A358 Gr 316 spool | CS pipe spool |
|---|---|---|
| Chemical Resistance | Highly resistant | Limited resistance |
| Corrosion Resistance | Excellent | Less corrosion resistance |
| Pitting & Crevice | Excellent resistance | Prone to pitting and crevice corrosion |
| Temperature Resistance | Retains corrosion resistance at elevated temperatures | Corrosion may occur at high temperatures |
| Corrosion | chloride-rich environments | chloride-rich environments |
| Compatibility | Compatible with a wide range of materials (easily welded and fabricated) | Limited compatibility (additional coating ) |
Manufacturer of ASME SA 358 tp316 flange spool pipe fitting in size ranging from 8" to 72" for petroleum industry
Accomplished SS 316 pipe spool work in Thailand, Indonesia, Panama, and Kazakhstan.
ASME SA 358 tp316 prefabricated pipe spools
A358 Gr 316 flanged pipe spool
ASTM A358 type 316 tubing spools
SA358 type 316 Pipe spool with weld neck flange
A358 316 fabricated pipe spools
SA 358 gr 316 Spool Pipe with Two side flange
ASTM A358 Grade 316 pipe spools equivalent properties
| Standard | JIS | WNR. | BS | UNS | GOST | EN | AFNOR |
|---|---|---|---|---|---|---|---|
| SS 316 | SUS 316 | 1.4401 / 1.4436 | 316S31 / 316S33 | S31600 | – | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 | Z7CND17-11-02 |
Looking for A358 tp316 spool piece pipe supplier in Mumbai? contact Reli pipe spool and get lowest price
SA358 type 316 tubing spool chemical properties
| Grade | Mn | Cr | C | S | Si | P | Mo | Fe | Ni |
|---|---|---|---|---|---|---|---|---|---|
| SS 316 | 2.0 max | 16.00 – 18.00 | 0.08 max | 0.030 max | 1.0 max | 0.045 max | 2.00 – 3.00 | 67.845 min | 11.00 – 14.00 |
A358 316 flange spool mechanical properties
| Grades | Yield Strength (0.2%Offset) | Melting Point | Tensile Strength | Density | Elongation |
|---|---|---|---|---|---|
| SS 316 | Psi – 30000 , MPa – 205 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | 8.0 g/cm3 | 35 % |
ASTM A358 Grade 316 pipe spools applications
Benefits of using ASTM A358 316 EFW Pipes Spools Fabrication
- Reduces manufacturing and NDT cost
- Weather-resistant construction
- Higher quality in comparison to on-site construction
- Improved safety in better manufacturing conditions
