SA106 tubing spools manufacturer India
Supplier of A106B prefabricated pipe spools in size ranging from NPS 1/4" to 30" diameter and Schedules 10 through 160, STD, XH and XXH
ASTM A106 grade B pipe spools specification
Size
- 1/2" NB to 24" NB in
A106 gr B prefabricated pipe spools standard
- ANSI B16.9
- MSS SP 43
Wall thickness
- 10s - Schedule XXS
SA106 gr B flange spools heat treatment
- PWHT
ASTM A106 B tubing spool welder test
- ISO 17025
- AWS ATF
Coatings
- Electro polish
- Epoxy and FBE coating
- Hot dipped galvanizingg
Welding standard
- Fabrication Tolarance – PFI ES3
- Bending PFI ES24
Fabrication parts
- 45° / 90° / 180° elbow (LR, SR)
- U Bend, Return Bend
- Tee / Reducing tee
- Weldneck / Blind / Slip on flanges
- Cross / Reducing cross
A106 B pipe spool fabrication end
- Plain end
- Beveled end
Looking for best quality of ASME SA106 B flanged pipe spool with beveling, cutting, and welding? contact us
ASME 106 pipe dimensions for fabrications
| Standard | ASTM A106-15 | |||||||
|---|---|---|---|---|---|---|---|---|
| Permissible Variations in Outside Diameter | NPS(") | Over 34 to 48 | Over 1-1/2 to 4 | 1/8 to 1-1/2 | Over 4 to 8 | Over 18 to 26 | Over 8 to 18 | Over 26 to 34 |
| OVER | 3/16” (0.187”) | 1/32” (0.031”) | 1/64” (0.015”) | 1/16” (0.062”) | 1/8” (0.125”) | 3/32” (0.093”) | 5/32” (0.156”) | |
| UNDER | 1/32” (0.031”) | 1/32” (0.031”) | 1/64” (0.015”) | 1/32” (0.031”) | 1/32” (0.031”) | 1/32” (0.031”) | 1/32” (0.031”) | |
A 106 gr B equivalent properties
| ASTM | ASME | EN | DIN | NFA | BS |
|---|---|---|---|---|---|
| ASTM A106 Grade B | ASME SA 106 Grade B | EN P235GH Grade 10216-2 | DIN 17175 Grade St 45.8 | ASTM A106 Grade B | NFA A 49-215 Grade TU 42-c |
Manufacturer of ISO certified ASTM A106 B fabricated spools in class 150 to 2500# pressure ratings and 1G TIG, 1G MIG, MIG/ MAG, GTAW weldings
We are high quality SA106 tubing spools manufacturer in India, we provide ASTM A106 grade B fabrication spool in Denmark, Cambodia and Australia
A106 prefabricated pipe spools
SA 106 gr B fabricated spools
ASTM A106 gr B flanged pipe spool
A106 gr B spool Pipe with two side flange
A106B carbon steel tubing spools
ASME SA106 pipe spool with weld neck flange
Stockists of A106 gr B spool flange with B16.9 pipe fittings and B16.5 flanges for oil and gas industry
ASTM A106 grade B pipe spools chemical compositions
| Grade | Chemical Composition % | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| C | P | Ni | S | Cr | Cu | Si | Mo | Mn | V | ||
| ASTM A106 | B | ≤0.30 | ≤0.035 | ≤0.40 | ≤0.035 | ≤0.40 | ≤0.40 | >0.10 | ≤0.15 | 0.29-1.06 | ≤0.08 |
A106 B smls fabricated pipe spools mechanical properties
| Grade | Yield Strength, min., psi | Tensile Strength, min., psi |
|---|---|---|
| Grade B | 35000 | 60000 |
Carbon steel ASTM A106 tubing spool value added services
- Positive Material Identification – PMI Testing
- Mechanical Testing Such as Tensile of Area
- Flattening Test
- Hardness Test
- Pitting Resistance Test
- Chemical Analysis – Spectro Analysis
- Flaring Test
- Micro and MacroTest
- Intergranular Corrosion (IGC) Test
ASTM A106 grade B pipe spools applications
- Food Processing & Dairy
- Refineries
- Oil and Gas Industry
- Pulp & Paper Industry
- Off-Shore Oil Drilling Companies
- Pharmaceutical Equipment
- Chemical Equipment
- Specialty Chemicals
- Sea Water Equipment
