Fabricated steel pipe fittings specification
Prefabricated fittings manufacturer
Dimensions
- 3 meter – 8" – 14"NB
Prefab spool standard
- ASME B16.5
- pressure class : Class 150 to 2500
Wall thickness
- 3mm to 70mm (Schedule 10S - XXS)
SS 304 prefabricated fittings heat treatment
- PWHT
- Normalizing,
- Tempering
Prefabricated piping material welder test
- ISO 17025
- AWS ATF
Fabrication process
- Cutting
- Beveling
- Welding
Prefab spools welding standard
- ASME section IX
- Welders as per API1104
Fabrication parts
- 45° / 90°elbow
- Elbow (LR/ SR)
- Tee / Reducing tee
- Cross / Reducing cross
- Weldneck / Blind / Slip on flanges
Key steps for prefabricated spool design
- Support and Pipe Routing
- Isometric drawings
- 3D Modeling
- Stress Analysis
Exporter of EN 10204 3.1 certified prefabricated pipes and pipe spools in MIG/MAG, GTAW, SAW, SMAW and FCAW welding
Supplier of SS 304 prefabricated fittings in hot dip galvanized coating in accordance with ISO 1461
Completed successfully fabricated fittings work in Guyana, Puerto Rica, Chile and Panama
Specialized in pre-fabrication of piping spools for oil and gas and petrochemical industry with 100% radiography test
Prefabricated pipe spools
SS 304 prefabricated fittings
Prefabricated pipes and pipe spools
