SS 321H Fabricated Spools Manufacturer in India
Stainless Steel 321H Pipe Spool Specification
AISI 321H Pipe Spool Size Range
- 6NB to 1200NB
SUS 321H Flanged pipe spool standard
- ASTM A312 / ASME SA312
- ANSI/ASME B36.10
Stainless Steel 321H Pipe Spool Wall thickness
- 0.3mm-50mm
UNS S32109 Tubing Spools Temperature
- 427 to 816°C
- 800 to 1500°F
DIN 1.4878 Flanged Spool Piece Welder Test
- AWS ATF
- ISO 17025
SS 321H Seamless Pipe Spool Fabrication Process
- Cutting
- Beveling
- Welding
DIN 1.4878 Prefabricated Spool Welding standard
- Bending PFI ES24
- ASME section IX
- Fabrication Tolarance – PFI ES3
INOX 321H Spool Piece Pipe Fabrication Parts
- Cross
- Tee
- Elbow
- flanges
321H SS Pipeline Spool Welding Methods
- MIG/ MAG
- GTAW
- GMAW
- SAW
- SMAW
- 1G TIG, 1G MIG
Supplier of UNS S32109 Flanged Pipe Spool in 5S to XXS Schedule at Low Cost in Mumbai
SS 321H Seamless Pipe Spool Size Chart
| Dia Nom(Inches) | 01/8 | 03/8 | 01/2 | 1 | 1 1/4 | 38 | 2 1/2 | 3 | 3 1/2 | 4 | 8 | 30 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| O.D. (mm) | 10.3 | 17.1 | 21.3 | 33.4 | 42.2 | 965 | 73 | 88.9 | 101.6 | 114.3 | 219.1 | 762 | |
| 5S | - | - | 1.65 | 1.65 | 1.65 | - | 2.11 | 2.11 | 2.11 | 2.11 | 2.77 | 6.35 | |
| 20 | - | - | - | - | - | - | - | - | - | - | 6.35 | 12.7 | |
| XS | 2.41 | 3.2 | 3.73 | 4.55 | 4.85 | 12.7 | 7.01 | 7.62 | 8.08 | 8.56 | 12.7 | 12.7 | |
| 40S | 1.73 | 2.31 | 2.77 | 3.38 | 3.56 | - | 5.16 | 5.49 | 5.74 | 6.02 | 8.18 | - | |
| S60 | - | - | - | - | - | - | - | - | - | - | 10.31 | - | |
| 160 | - | - | 4.78 | 6.35 | 6.35 | - | 9.53 | 11.13 | - | 13.49 | 23.01 | - | |
| 80S | 2.41 | 3.2 | 3.73 | 4.55 | 4.85 | - | 7.01 | 7.62 | 8.08 | 8.56 | 12.7 | - | |
| 100 | - | - | - | - | - | - | - | - | - | - | 15.09 | - | |
| 10S | 1.42 | 1.65 | 2.11 | 2.77 | 2.77 | - | 3.05 | 3.05 | 3.05 | 3.05 | 3.76 | 7.92 | |
| 120 | - | - | - | - | - | - | - | - | - | 11.13 | 18.26 | - | |
| XXS | - | - | 7.47 | 9.09 | 9.7 | - | 14.02 | 15.24 | - | 17.12 | 22.23 | - | |
| Dia Nom(Inches) | 12 | 14 | 16 | 42 | 18 | 20 | 24 | 26 | 32 | 36 | 44 | 48 | |
| O.D. (mm) | 323.9 | 355.6 | 406.4 | 1067 | 457 | 508 | 610 | 660 | 813 | 914 | 1118 | 1219 | |
| 5S | 3.96 | 3.96 | 4.19 | - | 4.19 | 4.78 | 5.54 | - | - | - | - | - | |
| 20 | 6.35 | 7.92 | 7.92 | - | 7.92 | 9.53 | 9.53 | 12.7 | 12.7 | 12.7 | - | - | |
| XS | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | |
| 40S | 9.52 | - | - | - | - | - | - | - | - | - | - | - | |
| S60 | 14.27 | 15.09 | 16.66 | - | 19.05 | 20.62 | 24.61 | - | - | - | - | - | |
| 160 | 33.32 | 35.71 | 40.49 | - | 45.24 | 50.01 | 59.54 | - | - | - | - | - | |
| 80S | 12.7 | - | - | - | - | - | |||||||
| 100 | 21.44 | 23.83 | 26.19 | - | 29.36 | 32.54 | 38.89 | - | - | - | - | - | |
| 10S | 4.57 | 4.78 | 4.78 | - | 4.78 | 5.51 | 6.35 | - | - | - | - | - | |
| 120 | 25.4 | 27.79 | 30.96 | - | 34.93 | 38.1 | 46.02 | - | - | - | - | - | |
| XXS | 25.4 | - | - | - | - | - | - | - | - | - | - | - |
PED Approved Stainless Steel 321H Pipe Spool Manufacturer in India, Offers SS 321H Seamless Pipe Spools in Variety of Sizes as per ASTM, DIN and ISO Standards at Lowest Price
UNS S32109 Flanged Spool
Stainless Steel 321H Fabricated Spool
AISI 321H Elbow Spool
321H SS Tee Spool
DIN 1.4878 Reducer Spool
SS 321H Prefabricated Pipe Spools
AISI 321H Flanged Pipe Spool Chemical Composition
| Element | Iron | Nickel | Chromium | Manganese | Titanium | Silicon | Phosphorous | Sulfur | Carbon |
|---|---|---|---|---|---|---|---|---|---|
| Fe | Ni | Cr | Mn | Ti | Si | P | S | C | |
| Content (%) | Balance | 09-Dec | 17-19 | 2 | 0.35 | 1 | 0.045 | 0.03 | 0.04-0.10 |
DIN 1.4878 Fabricated Pipe Spools Mechanical Properties
| Properties | Yield strength | Tensile strength | Hardness, Brinell | Elongation at break |
|---|---|---|---|---|
| Imperial | 29700 ksi | 69600 psi | ≤187 | 29% |
| Metric | 205 MPa | 480 MPa | ≤187 | 29% |
Trusted Stainless Steel 321H Pipe Spool Supplier in India, Offers INOX 321H flanged pipe spool in Various Wall Thickness as per Client Requirements
321H Stainless Steel Flange Spool Pipe Fitting Equivalnet Grades
| EN | EU |
|
|---|---|---|
| JIS | Japan |
|
| - | USA |
|
| AFNOR | France |
|
| UNI | Italy |
|
| BS | England |
|
| SS | Sweden |
|
| ISO | Inter |
|
| GOST | Russia |
|
