SS 317 Flanged Spool Manufacturer in India
Table of Content
Stainless Steel 317 Pipe Spool Specification
Stainless Steel 317 Pipe Spool Size Range
- 1/8 in to 12 in NPS
AISI 317 Flanged pipe spool standard
- ASME B16.5
- ANSI, JIS, ISO
SUS 317 Fabricated Spool Wall thickness
- 0.6 mm to 12.7 mm
UNS S31700 Tubing Spools Temperature
- 1010-1121°C
- 1850-2050°F
SS 317 Flanged Spool Piece Welder Test
- AWS ATF
- ISO 17025
Stainless Steel 317 Pipe Spool Fabrication Process
- Welding
- Beveling
- Cutting
SS 317 Seamless Pipe Spool Welding Standard
- ASME section IX
- Bending PFI ES24
- Welders as per API1104 (Uphill/ Downhill )
DIN 1.4449 Spool Piece Pipe Fabrication Parts
- Tee / Reducing tee
- Elbow (LR / SR)
- 45° / 90°elbow
- Cross / Reducing cross
- Weldneck / Slip On / Blind flanges
INOX AISI 317 Pipeline spool welding methods
- MIG/ MAG
- GTAW
- GMAW
- SAW
- SMAW
- 1G TIG, 1G
Supplier of UNS S31700 Fabricated Pipe Spools in Different Sizes With EN 10204 3.1 Certificates
AISI 317 Flanged Pipe Spool Size Chart
| Production method | Seamless Fabricated | Welded Fabricated | ||
|---|---|---|---|---|
| Size range | 0.5 – 24 Inch | 0.5 – 74 Inch | ||
| Wall Thickness (Schedule ) | Max thick (mm) | Sch XXS | 70 mm | 70 mm |
| Min thick (mm) | Sch 10S | 3 mm | 6 mm | |
PED Approved Stainless Steel 317 Pipe Spool Manufacturer in India, Provide SS AISI 317 Flanged Pipe Spool in Custom Option as per Client Requirement at Factory Cost
Types of Stainless Steel 317 Pipe Spool
SS 317 Elbow Spool
UNS S31700 Tee Spool
DIN 1.4449 Reducer Spool
SUS 317 Flanged Spool
AISI 317 Fabricated Spool
317 SS Prefabricated Pipe Spools
INOX AISI 317 Prefabricated Pipe Spools Chemical Composition
| Grade | C | Ni | Mn | P | S | Si | Cr | Mo | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 317 | max. | 0.8 | 14.0 | 2.0 | 0.040 | 0.03 | 1.00 | 20.0 | – | – |
| min. | – | 11.0 | – | – | – | – | 18.0 | – | ||
UNS S31700 stainless steel tubing spools Mechanical Properties
| Grade | 317 | |
|---|---|---|
| Density (kg/m3) | 8000 | |
| Elastic Modulus (GPa) | 193 | |
| Mean Coefficient of Thermal Expansion (m/m/0C) | 0-1000C | 17.2 |
| 0-5380C | 18.4 | |
| 0-3150C | 17.8 | |
| Thermal Conductivity (W/m.K) | at 5000C | 21.5 |
| at 1000C | 16.2 | |
| Electrical Resistivity (n.m) | 720 | |
| Specific Heat 0-1000C (J/kg.K) | 500 | |
317 SS Fabricated Pipe Spools Equivalent Properties
| Grade | 317 |
|---|---|
| UNS | S31700 |
| WNR | 1.4449 |
Trusted Stainless Steel 317 Pipe Spool Supplier in India, Offers 317 SS Fabricated Pipe Spools in Different Wall Thickness at Reasonable Price in Mumbai
SUS 317 Pipe Spooling Physical Properties
| Density | 68 °F | 0.29 |
|---|---|---|
| Electrical Resistivity | 77 – 932°F | 10.1 |
| Coefficient Of Thermal Expansion | 31.1 | |
| Thermal Conductivity | 77 – 212°F | 9.2 |
| Melting Range | 32 – 212°F | 0.11 |
| Modulus Of Elasticity | 77 – 1832°F | 10.8 |
| Specific Heat | 68 – 1832°F | 14.6 |
