A358 TP304 fabricated spools manufacturer in India
Looking for ASTM A358 gr.304 cl1 tubing spools fabrication as per ASME B31.3 code? contact Reli pipe spool and get best quality
ASTM A358 grade 304 pipe spools specification
Sizes
- 8 NB to 110 NB
ASTM A358 304 tubing spool standard
- ASME B16.9
- MSS SP-97
- ASME B16.5
Wall thickness
- Schedule 10S - XXS
- 3mm to 60mm
A358 TP304 fabricated spools heat treatment
- Preheating
- PWHT
ASTM A358 gr.304 cl1 flange spool welder test
- ISO 17025
- AWS ATF
A358 TP304 spool fabrication process
- Dimensioning
- Bending
- Cutting
- Welding
ASTM A358 gr 304 spool piece flange finishes
- Hot rolled(HR)
- Cold rolled(CR)
- 2B
- 2D
- BA NO(8)
- SATIN
Fabrication parts
- Cross / Reducing cross
- Tee / Reducing tee
- 45° / 90°elbow (LR, SR)
- Weldneck / Blind / Slip on flanges
Key steps for A358 TP304 pipeline spool design
- Support and Pipe Routing
- 3D Modeling
- Stress Analysis
- Isometric drawings
Manufacturer of A358 gr 304 pipe spool flange fabrication with A403 elbow and A182 F304 flanges
A358 TP304 fabrication spool equivalent properties
| Standard | UNS | WNR. | JIS | AFNOR | GOST | BS | EN |
|---|---|---|---|---|---|---|---|
| SS 304 | S30400 | 1.4301 | SUS 304 | Z7CN18‐09 | 08Х18Н10 | 304S31 | X5CrNi18-10 |
Trusted ASTM A358 304 EFW Pipes spools Manufacturer in India
ASTM A358 Grade 304 spool flange chemical composition
| Grade | N | Si | Mn | P | Cr | S | Mo | C | Ni | |
|---|---|---|---|---|---|---|---|---|---|---|
| 304 | min. | – | – | – | – | 18.0 | – | – | – | 8.0 |
| max. | 0.10 | 0.75 | 2.0 | 0.045 | 20.0 | 0.030 | 0.08 | 10.5 | ||
Exporter of ASTM A358 304 prefabricated pipe spools as per ASME B16.5 and pressure ratings CL 150 To CL 2500 for LNG gas and cryogenic industry
Successfully done SS 304 pipe spool work in Singapore, Indonesia, Bahamas and Kazakhstan
Types of A358 TP304 pipe spools
ASTM A358 Grade 304 prefabricated spool
A358 gr 304 fabricated pipe spools
ASTM A358 304 flanged pipe spool
A358 TP304 double flanged pipe spools
ASTM A358 gr.304 cl1 tubing spools
A358 304Spool Pipe with Two side flange
ASTM A358 gr 304 tubing spools mechanical properties
| Element | Density | Tensile Strength | Melting Point | Elongation | Yield Strength (0.2%Offset) |
|---|---|---|---|---|---|
| SS 304 | 8.0 g/cm3 | Psi – 75000, MPa – 515 | 1400 °C (2550 °F) | 35 % | Psi – 30000, MPa – 205 |
Supplier of ASTM A358 SS 304 custom pipe spool with 1G, 2G and 3G girth welds
A358 gr 304 pipeline spool sizes
| Dia Nominal (") | 3/8 | 1 | 1/8 | 1/2 | 1 1/4 | 38 | 3 1/2 | 2 1/2 | 3 | 4 | 12 | 8 | 30 | 14 | 18 | 16 | 42 | 20 | 26 | 24 | 32 | 48 | 36 | 44 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| O.D. (mm) | 17.1 | 33.4 | 10.3 | 21.3 | 42.2 | 965 | 101.6 | 73 | 88.9 | 114.3 | 323.9 | 219.1 | 762 | 355.6 | 457 | 406.4 | 1067 | 508 | 660 | 610 | 813 | 1219 | 914 | 1118 |
| 20 | - | - | - | - | - | - | - | - | - | - | 6.35 | 6.35 | 12.7 | 7.92 | 7.92 | 7.92 | - | 9.53 | 12.7 | 9.53 | 12.7 | - | 12.7 | - |
| 40S | 2.31 | 3.38 | 1.73 | 2.77 | 3.56 | - | 5.74 | 5.16 | 5.49 | 6.02 | 9.52 | 8.18 | - | - | - | - | - | - | - | - | - | - | - | - |
| 5S | - | 1.65 | - | 1.65 | 1.65 | - | 2.11 | 2.11 | 2.11 | 2.11 | 3.96 | 2.77 | 6.35 | 3.96 | 4.19 | 4.19 | - | 4.78 | - | 5.54 | - | - | - | - |
| XS | 3.2 | 4.55 | 2.41 | 3.73 | 4.85 | 12.7 | 8.08 | 7.01 | 7.62 | 8.56 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 | 12.7 |
| S60 | - | - | - | - | - | - | - | - | - | - | 14.27 | 10.31 | - | 15.09 | 19.05 | 16.66 | - | 20.62 | - | 24.61 | - | - | - | - |
| 80S | 3.2 | 4.55 | 2.41 | 3.73 | 4.85 | - | 8.08 | 7.01 | 7.62 | 8.56 | 12.7 | 12.7 | - | - | - | - | - | - | ||||||
| 160 | - | 6.35 | - | 4.78 | 6.35 | - | - | 9.53 | 11.13 | 13.49 | 33.32 | 23.01 | - | 35.71 | 45.24 | 40.49 | - | 50.01 | - | 59.54 | - | - | - | - |
| 100 | - | - | - | - | - | - | - | - | - | - | 21.44 | 15.09 | - | 23.83 | 29.36 | 26.19 | - | 32.54 | - | 38.89 | - | - | - | - |
| 120 | - | - | - | - | - | - | - | - | - | 11.13 | 25.4 | 18.26 | - | 27.79 | 34.93 | 30.96 | - | 38.1 | - | 46.02 | - | - | - | - |
| 10S | 1.65 | 2.77 | 1.42 | 2.11 | 2.77 | - | 3.05 | 3.05 | 3.05 | 3.05 | 4.57 | 3.76 | 7.92 | 4.78 | 4.78 | 4.78 | - | 5.51 | - | 6.35 | - | - | - | - |
| XXS | - | 9.09 | - | 7.47 | 9.7 | - | - | 14.02 | 15.24 | 17.12 | 25.4 | 22.23 | - | - | - | - | - | - | - | - | - | - | - | - |
Application of ASTM A358 grade 304 pipe spools
- Household applications
- Kitchen benches
- Industrial applications
- Medical applications
- Construction applications
ASTM A358 gr.304 cl1 304 vs 316 spool
| Property | Stainless Steel 304 | Stainless Steel 316 |
|---|---|---|
| Corrosion Resistance | Good | Superior |
| Mechanical Properties | Excellent formability, weldability, and toughness. | Slightly higher tensile strength . |
| Applications | food processing and architectural structures. | marine, pharmaceutical, chemical processing |
| Cost | Generally more affordable than higher-grade stainless steels. | Moderately higher cost compared to 304 ss spool |
ASTM A358 304 EFW Pipes spools advantages
- Corrosion Resistance
- Hygienic Properties
- Durability
- Compatibility
- Cost-Effectiveness
